AMV11 UV-Vis Spectrophotometer | 190–1100 nm

AMV11 UV-Vis Spectrophotometer

Keywords: UV-Vis spectrophotometer, single-beam UV-Vis spectrophotometer, 190–1100 nm spectrophotometer, UV spectrophotometer with scan software, laboratory spectrophotometer

The AMV11 Series is a single-beam UV-Vis spectrophotometer for absorbance, transmittance, energy, and quantitative measurements across a 190–1100 nm wavelength range. Its automatic wavelength setting, 128 × 64-dot LCD, and built-in data storage support routine analysis in research and quality-control laboratories. Choose the AMV11 standard model or the AMV11PC configuration with PC scan software for expanded computer-based analysis.

Key Features

1.  Covers ultraviolet and visible measurements from 190 to 1100 nm with a 2 nm spectral bandwidth.

2.  Automatically sets wavelength and supports automatic zero and blank adjustment.

3.  Displays up to 200 groups of measurement data, with five groups per screen, and can show standard curves with their equations.

4.  Stores up to 200 standard-curve equations for convenient review and reuse.

5.  Retains stored measurement data after an unexpected power interruption.

6.  Deuterium and tungsten lamps can be switched independently to help extend lamp service life.

7.  A pre-aligned deuterium lamp design makes lamp replacement easier.

8.  The large sample compartment accommodates cuvettes with 5–100 mm path lengths when used with the appropriate optional holder.

9.  The AMV11PC adds PC scan software for quantitative analysis, kinetics, wavelength scans, DNA/protein testing, and multi-wavelength testing.

Technical Specifications

Parameter	Specification
Optical system	Single beam; grating with 1,200 lines/mm
Standards	ASTM D1003, ASTM D1044, ISO 13468, ISO 14782, JIS K7361, JIS K7136, JIS K7105, JJF 1303-2011, GB/T 2410-08
Wavelength range	190–1100 nm
Spectral bandwidth	2 nm
Wavelength accuracy	±0.5 nm
Wavelength repeatability	0.3 nm
Wavelength setting	Automatic
Photometric accuracy	±0.5% T
Photometric repeatability	0.3% T
Photometric range	−0.3 to 3 A; 0–200% T; 0–9999 C
Stability	±0.002 A/h at 500 nm
Stray light	0.1% T max
Display	128 × 64-dot LCD
Lamps	Deuterium and tungsten lamps
Detector	Silicon photodiode
Data output	USB
Printer port	Parallel port
Power requirements	AC 220 V / 50 Hz or 110 V / 60 Hz
Dimensions (L × W × H)	460 × 360 × 225 mm
Weight	18 kg
PC scan software	Included; quantitative, kinetics, wavelength scan, DNA/protein, and multi-wavelength functions

Applications

1.  Chemistry and biochemistry laboratory analysis.

2.  Petrochemical testing and quality control.

3.  Environmental monitoring and water or wastewater analysis.

4.  Food and beverage laboratory testing.

5.  Research and routine quality-control measurements that use UV-Vis absorbance or transmittance.

Optional

1.  PC scan software (included with AMV11PC).

2.  Printer and automatic cell holder.

3.  Optional cuvette holders for supported 5–100 mm path lengths.
